Ensure accurate and reliable energy monitoring with the EM519168 three-phase smart meter. This Class 1 meter supports both active forward and reverse energy measurement, meeting the stringent requirements of the latest MID standards for compliant billing. Equipped with an Infrared (IR) port for easy local data access and configuration, it also features a built-in battery to maintain display during power outages and a backlight for enhanced readability. Designed for straightforward DIN rail mounting.
1.Product Introduction
The EM519168 is a high-precision (Class 1) three-phase smart meter designed for accurate energy measurement. Operating at 3x230/400V and 5(80)A, this meter supports bi-directional active energy metering and complies with the latest MID standards. It features an IR port for local communication, a built-in battery for power outage display, a convenient backlight for easy reading, and is designed for simple DIN rail installation.
2.Key Features
Accuracy: Class 1 precision.
Voltage and Current: 3x230/400V, 5(80)A.
Metering Functionality: Supports active forward and reverse energy measurement (Bi-directional).
MID Compliance: Meets the latest MID standards.
Communication: Integrated IR (Infrared) port for local data access.
Power Outage Feature: Built-in battery for display during power loss.
Readability: Backlight for clear display in various conditions.
Installation: DIN rail mounting for easy installation.
3.Technical Parameters
| Type | EM519168 | EM519171 | EM519167 | EM519173 |
| Battery | YES | N/A | YES | N/A |
| Power outage display | YES | N/A | YES | N/A |
| LCD backlight | YES | N/A | YES | N/A |
| Voltage | 3*230/400V | |||
| Current | 5(80)A | |||
| Accuracy | Class 1 | |||
| Frequency | 50Hz/60Hz | |||
| Display | LCD 6+2 | |||
| Communication | IR | RS485 | ||
| Pulse Constant | 1000imp/kWh | |||
| SO Output | Indicates active power, SO output is configurable (default 1000) | |||
| Measurement model | 1. Total = Forward2. Total = Reverse3. Total = Forward + Reverse (default)4. Total = Forward - Reverse5. Total = Forward - Reverse (margin) | |||
EM519168: Precise 3-Phase Meter with IR, MID Compliant
Get accurate energy readings with the EM519168 Class 1 meter. Supporting bi-directional metering and meeting the latest MID standards, this 3x230/400V, 5(80)A meter includes an IR port, battery for outage display, and a backlight. Easy DIN rail installation.
